PV Solar Mounting System
我们的产品造型美观、质量可靠、规格齐全、性能优越，深受客户好评，具有良好的市场美誉度。
产品描述
Ground mounting system can be applied to different geographical environment through rational design. Suitable for large power station project. It is widely used as the common installation methods. Ground mounting system uses galvanized steel or aluminum alloy frame structure, its installation is simple and fast. Ground system can be used in both solar polycrystalline silicon and amorphous silicon components.
C-profile steel ground mounting system can be applied to different geographical environment through rational design. Suitable for large power station project. It is widely used as the common installation methods. Its installation is simple and fast and can be used in both solar polycrystalline silicon and amorphous silicon components.
Technical parameters：
Installation site: Open ground
Installation angle: Any
Snow Load:1.4KN/m²
Wind Load:＞ 32m/s(grade12)
Wind Pressure:66.5kg/m²
Mounting color:Natural
Solar panel size: Any
Solar Mount Rail:Zinc galvanized steel
Warranty:20years
National Standard:GB/T13912/2002
Catagory：
Aluminum alloy ground mounting system
C-profile steel ground mounting system (Spiral foundation)
Single-post ground mounting system (Spiral foundation)
Double-row post ground mounting system (Cement foundation)
Single-post ground mounting system (Cement foundation)
Other：
Roof mounting system 、Adjustable-pitch solar mounting system
